Pipe supports
Our industry is renowned for failing to meet the demands of its customers, Hanley Solutions have quickly built a reputation for providing a quick reliable service from stock, at competitive rates, and with the personal touch that our customers have come to appreciate.
Channel Sections
Channel and brackets are manufactured to BS6946. All loading calculations are in accordance with BS5950. Standard Slot Sizes are 28 x 14mm @ 50mm Centres or 25 x 11mm @ 50mm Centres.
Standard Lengths are 3m and 6m, with cut lengths available on request.
The standard stock profile of Hanley Solutions channel is:
- PG = Pre-galvanised mild steel to BS EN 10326
- GA = Hot dip galvanised after manufacture to BS EN ISO 1461 (Other finishes are manufactured to customer requests)
- SS = Stainless steel 316
- EC = Epoxy Painted Finish
- PO = Plain Oiled Self Colour
Channel Brackets
Our ranges of brackets are designed to compliment our range of support systems, offering flexibility and integrity.
- Brackets are manufactured to comply with BS6946. All our brackets are manufactured from 40mm x 5mm or 40mm x 6mm thick steel that complies with BS EN 1011, with a minimum yield stress of 170 N/mm21.
- All brackets are 40 mm wide and have 14 mm diameter holes to accept maximum M12 setscrews. All bend radii are 5 mm unless otherwise stated. Maximum loads for individual brackets are available upon request. Bracket weights are indicated. All dimensions are in millimetres.
- Channel nuts and setscrews are not supplied with brackets and must be ordered separately. The standard finish for al brackets is hot dip galvanised to BS EN ISO 1461.
- Brackets are also available in Zinc Plated to BS EN 12329 malleable Iron, rubber lined. Stainless steel 316 is also available upon request.
